HypotMAX® 7720

20 kV @ 5 mA DC Hipot Tester, CE listed


The 7720 is part of the HypotMAX® Series, the automated line of High Voltage Withstand Testers designed to meet the demanding requirements of high voltage applications. If your application requires a high voltage DC Hipot test, the 7720 High Voltage Hipot Tester is sure to satisfy all of your Hipot testing needs.

Safety Features: Safety Interlock, SmartGFI®
Productivity: Arc Detection, Cal Alert®, PLC Remote Inputs and Outputs, Low-Current Sense, Electronic Ramping
Warranty: 5 Year Warranty
Dimensions (W x H x D): 16.93" x 5.24" x 15.75" (430 x 133 x 400 mm)

Weight: 48.9 lbs (22 kg)

$9,299.00
$9,299.00


DC Hipot
Voltage Output = 0.00-20.00kVDC
Leakage Current Limits = 0.0µA-5.000mA
DC Ripple ≤ 5% Ripple RMS at 20kVDC @ 4999uA, Resistive Load


HypotMAX Instrument
Interlock Connector Male
Input Power Cable USA
20 kV High Voltage Lead 5 FT
Return Lead 5 FT
USB Cable
3U Rack Mount Bracket
3U Rack Mount Handle
Rack Mount Handle Screws
Fuse
