HypotMAX 7710

12 kV @ 10 mA DC Hipot Tester, CE listed


The 7710 is part of the HypotMAX® Series, the automated line of High Voltage Withstand Testers designed to meet the demanding requirements of high voltage applications. If your application requires a high voltage DC Hipot test, the 7710 High Voltage Hipot Tester is sure to satisfy all of your Hipot testing needs.

Safety Features: Safety Interlock, SmartGFI®
Productivity: Arc Detection, Cal Alert®, PLC Remote Inputs and Outputs, Low-Current Sense, Electronic Ramping
Warranty: 5 Year Warranty
Dimensions (W x H x D): 16.93" x 5.24" x 15.75" (430 x 133 x 400 mm)
Weight: 63.1lbs (28.6 kg)

$7,299.00
$7,299.00


DC Hipot
Voltage Output = 0.00-12.00kVDC
Leakage Current Limits = 0.0µA-10.00mA
DC Ripple ≤5% Ripple RMS at 12kVDC @ 9999uA, Resistive Load





HypotMAX Instrument
Interlock Connector Male
Input Power Cable USA
12 kV High Voltage Lead 5 FT
Return Lead 5 FT
USB Cable
3U Rack Mount Bracket
3U Rack Mount Handle
Rack Mount Handle Screws
Fuse
